product
Roof | 0.5mm color steel |
Ceiling panel | 50mm glass wool sandwich panel |
Wall panel | 75mm EPS color steel sandwich panel |
Corner column | 50*25*2.0mm Galvanized steel |
partition wall | 50mm EPS color steel sandwichpanel |
Top frame long side beam | 50*25*2.0mm Galvanized steel |
Floor substrate | 18mm Fire-reinforced cement fiberboard |
Floor panels | 2mm pVC flooring |
Expandable roof | 50mm EPS sandwich panel |
Roof frame long side beam | 2.5mmGalvanized steel |
Top frame short side beam | 60*40*2.0mm Galvanized steel |
Colum | galvanized steel plate |
Bottom frame beam | 50*50*3.0mm Galvanized steel |
Bottom frame beam | 10#GB channel steel |
Corner fitting | Standard container corners |
Short side beams | 60*40*2.0mm Galvanized steel |
Thickness | The thickness of the colorsteel composite plate:75mm |
Specifldation | Outer orange peel, inner flat |
The coreinsulation | EPS polystyrene board |
Bulk density | 10-12kg/m |
Combustion Performance | Class A non-combustible |
Thickness | Thickness ofthe surfacecoated steel plate: 0.3mminside and outside |
